Name: Sinotruk HOWO 20CBM Aviation Aircraft Tank Refueling Truck
SKU: 0

Product



LOCATION： Home > Products > Sinotruk Truck > Sinotruk HOWO 20CBM Aviation Aircraft Tank Refueling Truck

Sinotruk HOWO 20CBM Aviation Aircraft Tank Refueling Truck

Aviation refueler truck(also called aircraft refueler truck,helicopter refueler truck,fuel dispenser truck,oil bowser truck,off road refueling truck,4X4 aviation refueling truck) is used to transport Jet A,avialtion fuel,fuel,oil,diesel,gasoline,kerosene and so on.

Description

Specifications

Condition	New condition/Left hand drive/4x2
	Curb weight(kg)		8305 kg
	Loading weight(kg)		10000 kg
	Wheelbase(mm)		4800/5000 mm
	Front/Rear axle loading weight(kg)		6000/1000 kg
	Front/Rear overhang(mm)		1430/2370 mm
	Approach/Departure angle(°)		18/12
	Max. driving speed(km/h)		80 km/h
	Clutch		Reinforced diaphragm clutch
	Brakes		Service brake: dual circuit compressed air brake.
			Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels
			Auxiliary brake: engine exhaust valve brake
	Steering Gear		Power steering, hydraulic steering with power assistance
	Tire	Quantity	10pcs with one spare tire
		Specifications	10.00R20
	Fuel tank volume(L)		400 L
Transmission	Manual type, 8 Forwards and 2 reverse
Steering	Power steering, hydraulic steering with power assistance
Cab	It can accommodate three people, With Air conditioner
Engine	Brand		Cummins
	Model		B190 33
	Fuel type		Diesel
	Displacement(ml)		5900 ml
	Power(kw)		140 kw
	Horsepower(HP)		190 HP
	Cylinder number		6 pcs
	Emission standard		Euro 3
Upper & Equipment
Fuel tank	Capacity(cbm)		15.0 cbm
	Tank material		Aluminium alloy
	Thickness(mm)		5.0 mm
	Compartment quantity(pcs)		1 pcs
	Filling medium		Aviation kerosene
Fuel pump	Quantity(pcs)		1 pcs
	Model		China local brand
Notes	1, Aluminium alloy safety valve 1 pc
	2, Mechanical type Ladder
	3, Filter system including
	4, Control system
Remarks	Customized LOGO design as per customer needs!
