3 Axles 80 Ton Detachable Gooseneck Lowboy Trailer
Detachable gooseneck lowboy trailer are noted for their highly robust structure steel and high loading capacity from 60 ton load capacity to 150 ton load capacity. We can provide you the customize detachable lowboy trailer to meet your transport requirements.
Email
WhatsApp

Description

Specification

  Dimension  16250x3000x700mm ( Working platform height )
  Working platform length  7600mm
  The rated load  40-80Ton
  Tare weight  About 17T
  Hydraulic power station  12KW JAC brand diesel engine
  Gooseneck  Hydraulic detachable type gooseneck
  Chassis  Axle  3 * 16Ton AN brand axle
  King Pin  3.5 inch bolt-in king pin , JOST brand
  Suspension  Mechanical suspension
  Rim  8.25-22.5 * 12pcs
  Tire  11R22.5*12 pcs, Chinese brand
  Brake Chamber  WABCO RE 6 relay valve
  Electrical system  24 volt electrical system
  Packing and shipping  Painting

  Complete Chassis sand blasting to clean rust, 1 coat of

  anti-corrosive prime, 2 coats of final paint

  Shipping Terms  By Bulk Cargo / RORO ship




80Ton Detachable Gooseneck Lowboy Trailer Features:

A: The working platform is as close to the ground as possible for transport of high and voluminous loads.

B: 250 mm side swing bracket on the both sides for increasing the overall width of lowboy trailer.

C: Length and width of dimensions of lowboy trailer is available custom made.
