Name: 20ft Skeleton Shipping Container Trailer
SKU: 0

Product



20ft Skeleton Shipping Container Trailer

2 axles skeleton shipping container trailer is popular in Asia and African market

Description

Specifications

Dimension	Length	Approx 7,210 mm
	Width	Approx 2,480 mm(including mudguard)
	Height	Approx 1,481mm @ unload
Weight	Max. Payload: Approx 30,000 kg
Steel Structure	Material	High strength low alloy steel Q345 and Q235 is used for welded I-beam and fabricated parts.
	Axle	2*13 tons Fuwa axles
	Tire	11R22.5 tires, 8pcs
	Suspension	reinforced mechanical suspension
	King Pin	2" bolting kingpin.
	Twist lock	4 units ISO retractable twist locks
	Landing Gear	JOST E100 landing gear
	Brake System	Dual air brake system, WABCO relay valve, No ABS system.
	Brake chamber	Type30/30 on the two axles.
	Electrical System	24-volt lighting system, 7-way receptacle, Chinese standard.
