27000 liters Hydrochloric Acid Tanker Trailer
V Shape Acid Tanker trailer use high quality materials and spare parts to ensure the tank to be a good condition in acid transport.With many years of R&D and improve,more and more transporter can get more benefit from our trailers.

Description

Specifications

  Dimension(L*W*H)mm  11900*2500*3500
  Payload(kgs)  40000
  Tare weight(kgs)  8000
  Effective capacity  22cbm
  Medium  acid
  Kingpin  3.5” bolt-in
  Landing gear  19”
  Tire size  12R22.5 (13sets)
  Rim size  9.00*22.5 (13sets)
  Axle  13 ton
  Leafs spring  Steel suspension with 8 pcs of leafs spring
  Brake system  Dual line with WABCO brand Re-6 emergency relay valve, MBA brand T30/30 air chamber, 46L air tank
  Discharge valve  DN100mm discharge valve with cover
  Manhole  European standard Φ500 with air valve
  Spill boxes  Spill boxes with vent valves, Drainage pipes fitted
  Tank roof  Anti-corrosion cover
  Discharge hose  2 units anti-corrosion hose on both ends
  Prime & Topcoat painting  With painting
